Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black

Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black

Black
$138.88 USD $229.99 USD
Skip to product information
X Series badgeColor Night IQ Plus badge
Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • X5 Bullet 3D Model
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
  • X5 Bullet 3D Model
Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black
X Series|
CNE01P-1BB-AB1

Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+ - White/Black (Cable not included)

Key Features:

  • No Monthly Fees
  • Recorder Required (Wired)
  • Compatible with X Series Recorders
  • 4K Ultra HD Resolution
  • Smart Motion Detection
  • Advanced Deterrence
  • Real-time 30fps Recording
  • Long-distance PoE
  • Nano Intelligence Codec
  • Two-Way Audio
  • IP66 Weatherproof Rating
  • Works with the Lorex Connect mobile app
  • Wide Dynamic Range (WDR)
ColorBlack

Become a Partner and Log in to access volume pricing, build your system, and place orders.

ONVIF® conformant

ONVIF is a global open standard for IP-based security products. ONVIF certification helps support integration between compatible IP cameras, NVRs, VMS platforms, and software that use the same ONVIF profiles.

  • Works with compatible ONVIF-conformant systems
  • Supports third-party devices and VMS integration
  • Supports ONVIF Profile G, M, S, T*
Learn More

*ONVIF compatibility varies by model. Advanced features may not work with third-party cameras. Click here to check compatibility test results.

Become a Partner and Log in to access volume pricing, build your system, and place orders.

🛈
Camera cables are sold separately.

Add-Ons

Quick Order

Become a Partner and Log in to access volume pricing, build your system, and place orders.

Overview

The Lorex Connect X Series 4K PoE Camera is a professional-grade security camera that pairs uncompromised image quality with intelligent detection, operational analytics, and open-platform compatibility — helping businesses protect assets, streamline operations, and scale with ease.
Learn More

Complete Your System

Pair with other X Series products for smarter detection, unified control, and effortless setup.

X Series badge
Lorex Connect X Series 2K+ Dual-Lens PTZ Camera with 30× Optical Zoom

Lorex Connect X Series 2K+ Dual-Lens PTZ Camera with 30× Optical Zoom

Lorex Connect X Series 2K+ Dual-Lens PTZ Camera with 30× Optical Zoom (Cable not included)

Become a Partner and Log in to access volume pricing, build your system, and place orders.

Lorex Connect X Series 2K+ Dual-Lens PTZ Camera with 30× Optical Zoom

Product Compatibility List

AI Video Analytics

What's Included

X5 4K PoE Bullet Camera

Mounting Hardware

Weather-Resistant RJ45 Cable Gland

DORI Distance

DORI stands for Detect, Observe, Recognize, and Identify. It describes increasing levels of visual detail used to assess surveillance camera performance at distance.

Detect

80.4 m / 263.8 ft

Detect level DORI example

Observe

32.2 m / 105.6 ft

Observe level DORI example

Recognize

16.1 m / 52.8 ft

Recognize level DORI example

Identify

8.0 m / 26.2 ft

Identify level DORI example

Product Specifications

Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+

Download PDF
Resolution
4K (3840 × 2160)
Lens
Fixed 2.8 mm / F1.0
Field of View
Horizontal: 109.4°
Night Vision
Color Night IQ+
Weather Rating
IP66
Power
12V DC / PoE
Local Storage
MicroSD up to 1 TB
Integration
ONVIF, RTSP

Camera

7 specs
Image Sensor
8MP 1/1.8” CMOS
Max Resolution
4K (3840 × 2160)
Max Frame Rate
30 fps
Aspect Ratio
16:9
True WDR
120 dB
Min Illumination
Color: 0.0005 lux/ B/W (IR On): 0 lux
Signal-to-Noise Ratio
55 dB

Lens

4 specs
Type
Fixed
Focal Length / Aperture
2.8 mm / F1.0
Field of View
  • Diagonal: 113.8°
  • Horizontal: 109.4°
  • Vertical: 59.5°
DORI Distance
  • Detect: 263.8 ft (80.4 m)
  • Observe: 105.6 ft (32.2 m)
  • Recognize: 52.8 ft (16.1 m)
  • Identify: 26.3 ft (8.0 m)

Video

4 specs
Compression
  • Nano Codec (Enhanced H.265 Compression)
  • H.265
  • H.264
  • MJPEG
Video Streams
Main / Sub / Third Stream
Bit Rate Control
CBR / VBR
Video Format
NTSC

Audio

3 specs
Microphone
Yes
Speaker
Yes
Two-Way Talk
Yes

Night Vision

2 specs
IR Night Vision
Yes, up to 98 ft (30 m) in total darkness
Color Night IQ+
Yes

AI Smart Features

5 specs
Detection
  • Person
  • Vehicle
  • Face Recognition
  • Intrusion
  • Loitering
  • Wrong-Way
  • Unauthorized Parking
Perimeter Protection
Line-Crossing, Dual-Line Crossing
Tracking & Monitoring
Smart Motion
Crowd Analytics
Heat Map, People Counting
Active Deterrence
  • Red and Blue Light
  • White Light
  • Siren
  • Pre-Recorded Messages¹

Network & Connectivity

2 specs
Interface
RJ45 (10/100 Base-T)
Protocols / Integration
ONVIF, RTSP

Storage & Power

3 specs
Local SD Storage
MicroSD Slot (Up to 1 TB)*
Power Supply
12V DC / PoE (IEEE 802.3af)
Max Power Consumption
7.1 W (DC) / 8.9 W (PoE)

Physical

5 specs
Housing Material
Aluminum Alloy
Colors
Black / White
Mounting Adjustment Range
Pan: 360° / Tilt: 90° / Rotation: 360°
Camera Dimensions (W × D × H)
7.4 × 3.15 × 3.03 in (188 × 80 × 77 mm)
Camera Weight
1.17 lb (0.53 kg)

Environmental

3 specs
IP Rating
IP66
Operating Temperature
-22°F to 140°F (-30°C to 60°C)
Operating Humidity
≤ 90% RH

Package Information

7 specs
Black
  • SKU: CNE01P-1BB-AB1
  • UPC: 6-95529-06630-1
White
  • SKU: CNE01P-1BW-AB1
  • UPC: 6-95529-06631-8
Package Type
Brown Box
Package Dimensions (W × D × H)
9.25 × 4.17 × 4.02 in (235.0 × 106.0 × 102.0 mm)
Package Weight
1.48 lb (0.67 kg)
Package Cube
0.0897 ft³ (0.00254 m³)
Package Contents
  • 1 × Lorex Connect X5 4K PoE Bullet Camera with Color Night IQ+
  • 1 × Mounting Template
  • 4 × Mounting Anchors
  • 4 × Mounting Screws
  • 1 × Allen Key
  • 1 × Weather-Resistant RJ45 Cable Gland

Model Information

3 specs
Series Family
X
Series Line
X5
SKU
  • CNE01P-1BB-AB1
  • CNE01P-1BW-AB1
Notes & disclaimers
  • ¹ Compatible with select Lorex Network Video Recorders. For a full list of compatible recorders visit: www.lorex.com/compatibility.
  • Color nighttime video typically switches to black & white IR night vision when there is not sufficient ambient light to ensure optimal low-light image quality.
  • Stated IR illumination range is based on ideal conditions in typical outdoor nighttime ambient lighting up to 98 ft / 30 m in total darkness. Actual range and image clarity depends on installation location, viewing area and light reflection/absorption.
  • Audio recording is disabled by default. Audio recording without consent is illegal in certain jurisdictions. Lorex Technology does not assume liability for any use of its product that fails to conform with local laws.
  • Not intended for submersion in water. Installation in a sheltered location recommended.
  • * A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing.
