Product Features
- Recorder Required (Wired)
- 4MP Resolution
- Smart Motion Detection
- Color Night Vision
- Listen-In Audio
- IP67 Weatherproof Rating
- Wide Dynamic Range (WDR)
Note: Camera cables are sold separately.
See everything, hear everything, worry about nothing. This Lorex 2K Security Camera delivers crystal-clear video day and night, along with premium features such as audio recording and smart motion detection for complete security. Built to endure extreme temperatures, this weatherproof camera will provide you with peace-of-mind around the clock for years to come.
In-Camera Video Analytics
Product Specifications
| Image Sensor | 4MP CMOS |
| Video Format | NTSC |
| Video Compression | H.265/H264 (Main Stream & Sub Stream) |
| Video Streams | 2 (Mainstream & Substream) |
| Viewing Angle (diaognal) | 114° |
| Lens/Lens type | 2.8mm F1.6/Fixed |
| Resolution/Frame rate | 4MP (2688 × 1520/2560 × 1440); 3MP (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Frame Rate (Maximum) | Mainstream: 2688 × 1520@(1–20 fps) 2560 × 1440@(1–25/30 fps) Substream: 704 × 576@(1–25 fps) 704 × 480@(1–30 fps) |
| WDR | Yes |
| Termination | RJ45 |
| Aspect Ratio | 16:9 |
| Microphone | Yes |
| Siren | No |
| Two-way Talk | No |
| Night Vision Range | 98ft (30m) |
| Color Night Vision | Yes |
| Smart Motion Detection | Yes |
| Detection Types | Vehicle and Person |
| Camera Housing Material | Alluminum Alloy |
| Power Requirements | PoE (Power over Ethernet Class -802.3af) / 12V DC |
| Power Consumption (max) | 5.1W (POE), and 4.2W (DC12V) |
| Camera Dimensions (D x H) | 3.9 x 4.8” 99.1 x 121.9mm |
| Camera Weight | 1.06lbs / 0.48kg |
| Operating Temperature | -40°F (-40°C) ~ +140°F (+60°C) |
| Humidity | ≤95% |
| Environmental Rating | IP67 |
| Certification | FCC, CE |
What's Included
- 12V DC Power Connector
- Ethernet Connector
- Release Tab
- IR (Infrared) Light
- Camera Lens
- Microphone
- Adjustment Screw
- Cable Notch
- MicroSD Card Slot*
- Reset Button
Package Contents:
4MP IP PoE Wired Turret Camera
Mounting Bracket
Mounting Kit
Weather-resistant Cap
*A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing
