Product Features
- Easy installation - Quick and hassle-free DIY setup
- Secure access control - Bluetooth deadlock with 2-layer encryption
- Convenient keyless entry - App access, keypad, or auto unlock
- Customize permissions - Manage up to 10 users
- Never forgot to lock your door - Schedule auto lock with preset times
- Track activity - View lock history through the Lorex App
- Resistance to forced entry - ANSI Grade 2 Certified
Add-Ons
Product Discontinued: Meet the next generation
Product Specifications
| Model | LK101-AA |
|---|---|
| Lock Type | Bluetooth deadbolt |
| Door Bore Hole | 2-1/8" (54 mm) or 1-1/2" (38 mm) |
| Door Thickness | 1-3/8" (35 mm) to 2" (51 mm) |
| Adjustable Backset | 2-3/8" (60 mm) and 2-3/4" (70 mm) |
| Unlock Method | Mechanical key, Entry code, Mobile App |
| User Entry Code | Program up to 200 sets |
| Mobile App | iOS and Android compatible |
| Mobile App Control | Monitor, grant, and revoke access |
| Touch Screen Back-light Color | White |
|---|---|
| Fire rated | UL 20 minute compliant |
| ANSI/BHMA | ANSI Grade 2 Compliant |
| Connectivity | Bluetooth |
| Power | Four AA 1.5V alkaline batteries |
| Operation Temperature | -31 °F to 150.8 °F / -35 °C to 66 °C |
| Dimension |
Exterior lock body : 2.59 × 1 × 5.34” / 66 × 25.8 × 135.8 mm Interior lock body : 2.64 × 1.7 × 6.28” / 67.1 × 43.55 × 159.6 mm |
| Weight | 2.45 lbs / 1.11 kg |
What's Included
| Part | Description | Quantity |
|---|---|---|
| A | Key | 2 |
| B | Exterior Assembly | 1 |
| C | Cylinder | 1 |
| D | Torque Blade | 1 |
| E | Power Cable | 1 |
| F | Mounting Plate | 1 |
| G | Interior Assembly | 1 |
| H | Battery Cover | 1 |
| I | Latch | 1 |
| J | Bottom Plate (Optional) | 1 |
| K | Square or Round Faceplate (Optional) | 1 |
| L | Drive-in Collar (Optional) | 1 |
| M | Strike Plate | 1 |
| N | Reinforced Strike Plate | 1 |
| O | Dust Box | 1 |
| Part | Description | Quantity |
|---|---|---|
| AA | 2-1/16" (52 mm) Mounting Bolt | 2 |
| BB | 1-1/4" (31.7 mm) Screw ［The correct hole sizes. Ø 2-1/8" (54 mm)] | 1 |
| CC | 3/4" (19 mm) Screw | 4 |
| DD | 3/4" (19 mm) Wood Screw | 1 |
| DD-1 | 1-1/4" (31.7 mm) Wood Screw | 2 |
| EE | 3" (76 mm) Wood Screw | 2 |
*Geolocation performance of Auto-Unlock may vary based on phone model and operating system. For a fully hands-free lock experience, enable the Auto-Lock feature. For more information and tips, please visit our support page here.
Product Support
LK101 Series - Bluetooth Deadbolt Smart Lock with Touchpad
