Product Features
- IP66 Weatherproof Rating
- Compatible with Select Lorex Security Cameras
- Outdoor junction box options
- Provides additional space for cabling and baluns
- Convenient installation
- Ceiling, wall and counter mounting
Add-Ons
Product Discontinued: Meet the next generation
Protect your camera cables from harsh weather, dust, and vandalism, while keeping your camera area neat and tidy with the Lorex junction box. Quickly and easily access the camera cables and connectors when needed without having to remove the camera. With the added cable protection, this junction box will help preserve your cameras for years to come.
Product Specifications
| Material | Aluminium |
|---|---|
| Finishing | Powder Spray |
| Color | White |
| Pipe Thread | G3/4" |
| Load-Bearing Weight | 6.61 lbs / 3 kg |
| Operating Temperature | -40 °F to 140 °F / -40 °C to 60 °C |
|---|---|
| Humidity | <90% RH |
| Ingress Protection | IP66 |
| Product Weight | 1.19 lb / 0.54 kg |
| Product Dimensions (W × D × H) | 5.27 × 5.25 × 2.05" / 134 × 133.5 × 52 mm |
What's Included
Package Contents:
Junction Box
(× 1)
Mounting Screw
(× 4)
Mounting Anchor
(× 4)
Allen Key
(× 1)
Machine Screw
(× 3)
Washer
(× 4)
Product Compatibility
Product Support
AJLD-1W Series - Outdoor Junction Box for Dome and Turret Cameras
